80mm Dust Extraction Pipe

I'm Online Chat Now
I am from Brazil,Thanks for your high quality products and good service.

—— Carlos

Your goods are sold well in our market.I will place the next order soon.

—— Mark

80mm Dust Extraction Pipe

80mm Dust Extraction Pipe
80mm Dust Extraction Pipe 80mm Dust Extraction Pipe

Large Image :  80mm Dust Extraction Pipe Get Best Price

Product Details:
Place of Origin: China
Brand Name: YP
Certification: ISO
Model Number: B10090
Payment & Shipping Terms:
Minimum Order Quantity: 50 units
Price: USD 2.5-6.8/unit
Packaging Details: wooden case
Delivery Time: 15 days
Payment Terms: L/C, D/P, T/T, Western Union, MoneyGram, D/A
Supply Ability: 50000 units per month
Detailed Product Description
Commodity: Dust Extraction Pipe Pressed And Seam Welded Bend 80-300mm Zinc Plated Application: Dust And Fume Extraction
Size: 80-300mm Thickness: 1mm,1.2mm
High Light:

dust collection pipe

,

dust extraction ducting

Dust Extraction Pipe Pressed And Seam Welded Bend 80-300mm Zinc Plated

Our pressed bends in standard sizes up to 300mm diameter are smooth, pressed bends for efficient flow, reduced pressure loss, and elimination of blockages. Radius is 1.5 x Diameter. The bends are available in 90°, 60°, 45°, 30°.


¢D

MM

90º 60º 45º 30º

R

MM

S
MM

80 B8090 B8060 B8045 B8030 120 1
100 B10090 B10060 B10045 B10030 150 1
125 B12590 B12560 B12545 B12530 187.5 1
140 B14090 B14060 B14045 B14030 210 1
150 B15090 B15060 B15045 B15030 225 1
160 B16090 B15060 B15045 B15030 240 1
180 B18090 B18060 B18045 B18030 270 1
200 B20090 B20060 B20045 B20030 300 1
225 B22590 B22560 B22545 B22530 337.5 1
250 B25090 B25060 B25045 B25030 375 1
275 B27590 B27560 B27545 B27530 412.5 1
300 B30090 B30060 B30045 B30030 450 1



Pipe Bends Application:

  • Chemical Architecture:Used to connect of chemical powder pipe and connect of the architecture pippe.
  • ​Leichtindustrie:Mainlly apply in the cleaning system of furniture factory and serious ​leichtindustries.
  • Sanitation environmental production department:Application of connection biowing off piping.

Features:
-quick assembly
- factory fitted seal with no loose fittings
-can be twisted and adjusted, but has no effect on the gas tighteness
-installation without sealant or solvents
-can be used in all kinds of climates
-the gas tighteness can keep good from 5000 Pa negtive pressure to 3000 Pa positive pressure
-both ends of the fittings are disposed with the process of turnup, which makes both ends smooth, reinforced and also underformed.
80mm Dust Extraction Pipe 0



Other related ductwork pipe fittings: duct clamps, blast gate, air damper, reducer, flanges


 80mm Dust Extraction Pipe 1 80mm Dust Extraction Pipe 2
