Modular Ductwork Pipe Fittings 60 Degree Pressed Bends For Dust Collection

I am from Brazil,Thanks for your high quality products and good service.

—— Carlos

Your goods are sold well in our market.I will place the next order soon.

—— Mark

I'm Online Chat Now

Modular Ductwork Pipe Fittings 60 Degree Pressed Bends For Dust Collection

China Modular Ductwork Pipe Fittings 60 Degree Pressed Bends For Dust Collection supplier
Modular Ductwork Pipe Fittings 60 Degree Pressed Bends For Dust Collection supplier Modular Ductwork Pipe Fittings 60 Degree Pressed Bends For Dust Collection supplier Modular Ductwork Pipe Fittings 60 Degree Pressed Bends For Dust Collection supplier Modular Ductwork Pipe Fittings 60 Degree Pressed Bends For Dust Collection supplier

Large Image :  Modular Ductwork Pipe Fittings 60 Degree Pressed Bends For Dust Collection

Product Details:

Place of Origin: China
Brand Name: YP
Certification: ISO
Model Number: B10090

Payment & Shipping Terms:

Minimum Order Quantity: 50 units
Price: USD 2.5-6.8/unit
Packaging Details: wooden case
Delivery Time: 15 days
Payment Terms: L/C, D/P, T/T, Western Union, MoneyGram, D/A
Supply Ability: 50000 units per month
Contact Now
Detailed Product Description
Product Name: Modular Ductwork Pipe Fittings 60 Degree Pressed Bends For Dust Collection Material: Galvanized Steel, Stainless Steel
Thickness: 1mm Diameter: 80-300mm
Application: Dust And Fume Extraction Color: Silver

Modular ductwork pipe fittings 60 degree pressed bends for dust collection

Keywords: Pressed bends , elbows, ventilation ducts parts

our pressed bends in standard sizes up to 300mm diameter are smooth, pressed bends for efficient flow, reduced pressure loss, and elimination of blockages. Radius is 1.5 x Diameter. The bends are available in 90°, 60°, 45°, 30°.

Application:


  • Chemical Architecture:Used to connect of chemical powder pipe and connect of the architecture pippe.
  • ​Leichtindustrie:Mainlly apply in the cleaning system of furniture factory and serious ​leichtindustries.
  • Sanitation environmental production department:Application of connection biowing off piping.

Modular Ductwork Pipe Fittings 60 Degree Pressed Bends For Dust Collection

The specifications of pressed bends:


¢D

MM

90º60º45º30º

R

MM

S
MM

80B8090B8060B8045B80301201
100B10090B10060B10045B100301501
125B12590B12560B12545B12530187.51
140B14090B14060B14045B140302101
150B15090B15060B15045B150302251
160B16090B15060B15045B150302401
180B18090B18060B18045B180302701
200B20090B20060B20045B200303001
225B22590B22560B22545B22530337.51
250B25090B25060B25045B250303751
275B27590B27560B27545B27530412.51
300B30090B30060B30045B300304501



Features:
-quick assembly
- factory fitted seal with no loose fittings
-can be twisted and adjusted, but has no effect on the gas tighteness
-installation without sealant or solvents
-can be used in all kinds of climates
-the gas tighteness can keep good from 5000 Pa negtive pressure to 3000 Pa positive pressure
-both ends of the fittings are disposed with the process of turnup, which makes both ends smooth, reinforced and also underformed.

Modular Ductwork Pipe Fittings 60 Degree Pressed Bends For Dust Collection

Modular Ductwork Pipe Fittings 60 Degree Pressed Bends For Dust Collection

Modular Ductwork Pipe Fittings 60 Degree Pressed Bends For Dust Collection

Other related ductwork pipe fittings: duct clamps, blast gate, air damper, reducer, flanges
Modular Ductwork Pipe Fittings 60 Degree Pressed Bends For Dust CollectionModular Ductwork Pipe Fittings 60 Degree Pressed Bends For Dust Collection
Modular Ductwork Pipe Fittings 60 Degree Pressed Bends For Dust CollectionModular Ductwork Pipe Fittings 60 Degree Pressed Bends For Dust Collection
